Technical Specifications
Technology : Input mains Switching with High Speed Realys
Rating: 10 kVA
Input Voltage: 140 V AC to 300 V AC
Frequency (I/P & O/P): 50 Hz + 10 %
Output Voltage: 230 V AC + 9 %
Transfer Time: < 1.5 ms
Switching Component: High Speed Relay / Thyristers
Surge Handling Capacity: Up to 1000 j
Efficiency: > 95 %
Total Harmonic Distortion (THD): < 3 %
Voltage Frequency Effect :Independent Voltage Control
Output Waveform: Pure Sine Wave - No Clipping
Overload Capacity: 130 % for 1 Hour
Protections: High / Low Cut Off & Overload
Cooling : Forced Air Cooled
Response Time : 10 ms (Typical)
Noise :< 20 dB (Measured at 1 meter distance)
Ambient Temperature: 1 Deg to 48 Deg Cal.
